1 – Modem Parameter Source
Configured Satellite Modem to read the Beam ID from the Controller, Modem or Beam ID Table. (HNS Ku
Only and iDirect).
C – Read Modem Frequency, Symbol Rate etc... from the controller configuration.
B – Read Modem Frequency, Symbol Rate etc... from the Configuration Table.
M – Read Modem Frequency, Symbol Rate etc... from the modem.
2 – Configured Satellite Modem Receive Frequency in MHz with no decimals (HNS Only)
3 – Configured Satellite Modem Symbol Rate in sps (HNS Only)
1Msps = 1000 Ksps = 1 000 000 sps
4 – Longitude & Hemisphere (HNS Only)
Modem longitude and Hemisphere.
5 – DVB Configuration (HNS Only)
The user can configure the type of carrier to search for either DVB-S1 or DVB-S2A. The DVB-S2
ACM carrier requires controller model 7710 Rev 1.0+ or greater.
6 – 22 KHz Tone (Enable/Disable) (HNS Only).
This feature allows users to enable/disable the 22 KHz tone for supporting LNB's
E – Enabled
D – Disabled
7 – Receive and Transmit Polarization.
HH – Horizontal Transmit, Horizontal Receive
HV – Horizontal Transmit, Vertical Receive
VH – Vertical Transmit, Horizontal Receive
VV – Vertical Transmit, Vertical Receive
7.10.3.
EL
The EL menu allows for the Configuration of the elevation axis, only configurable option is the
elevation offset.
1
O: 004.5
