C-COM Satellite Systems Inc.
7.7.
MONITOR
This section describes briefly what each item and menu represent. For a more detailed
explanation of each menu, see the configuration section of this manual.
MAIN
Displays real-time system status and receive signal.
EL
(Elevation) Displays real-time current drawn and speed settings for the
elevation motor, as well as real-time elevation angle and limits, offset,
window size, and Elevation adjustment gap.
AZ
(Azimuth) Displays real-time current drawn and speed settings for the
azimuth motor, as well as real-time azimuth angle and limits, window
size.
PL
(Polarization) Displays real-time current drawn and speed settings for
the polarization motor, as well as real-time polarization angle and limits,
window size, and PL zero.
GP
Displays GPS Status and coordinates.
SM
(Search Mode) Displays compass status, Search Mode (RF status).
S1
(Satellite) Displays Target Satellite longitude and the antennas target
coordinates. This branch also contains the DVB Carrier programmed
and the LNB Power
S2
(Satellite) Displays Reference Satellite longitude and the DVB Carrier
programmed for the reference satellite along with the LNB Power
MD
(Modem and Beacon Receiver) Displays Modem status as well as the
Beacon Receiver frequency and signal (if a beacon receiver is used)
IP
Displays IP of iNetVu 7710 Ethernet Port, and the VSAT modem.
GW
(Gateway) Displays Subnet, and Gateway IP.
MAIN
EL
AZ
PL
GP
S1
S2
MD
Fig. 16:
Monitor Menu
iNetVu™ 7710 Controller User Manual
SM
IP
GW
28
