1 – iNetVu 7710 Controller's IP Address
®
2 – Modem IP Address
7.10.12.
SR
This menu will allow the user to configure the controller to the service used (select modem type)
for 2-way satellite communication.
1
4
1 – Two-Way Mobile Service Selection
Before communication is established with the modem, the user must define the service in use. The
®
iNetVu 7710 Controller supports several services, including:
iDirect – iDirect Service
Tooway – Viasat Tooway Ka Service
VA_SB2 – Viasat SurfBeam2 Ka service
HNS_KU – Hughes Ku Service
HNS_KA – Hughes Ka Service
HNS_JT – Hughes Jupiter Service on HT series modems
COMTCH – Comtech Service
IPstar – IPstar Service
GILAT – Gilat Service on SkyEdge
NEWTEC – Newtec Ku service (OpenAMIP)
NV_SAT – NovelSat Service
DATUM7 – Datum Service
STM – STM Satlink service
NA - Stand Alone service - Used to locate and lock onto a manually configured satellite using the
DVB receiver unit inside of the controller independent of the modem. The manual configuration
requires:
2
HNS_KU – TYPICAL - HT--0
YE(Y)NN
6
5
Fig. 44: SR (Service) Configuration
▪
Orbital Slot of Satellite
▪
Receive Polarization
▪
DVB Type
▪
L-Band or Ku-Band Rx Frequency (kHz)
▪
Symbol Rate (ksps)
▪
FEC Code Rate
