7 – Restore Compass Factory Calibration (CPR)
Restores the compass to factory calibration. Ensure the compass is levelled/flat when restoring to factory
calibration for optimum results.
8 – Stop
Stops the current operation.
7.9.

BEAM

The LCD Configuration Interface is password protected.
The default password is "password" (case sensitive).Use the "↑" or "↓" button to select the
characters, and the "←" or "→" to navigate through the character fields. Press on the "ENTER"
button of the front panel when the password has been completely entered.
If the password has been changed, and the user does not know the password, entering a
specific reset ID in the bottom row will reset the password to the default ("password"). The
Reset ID (RST) is "123456789"
SAT Allows the user to configure and save the Beam ID, Orbital slot /
Longitude of the desired Target Satellite (1-64 Satellite Beams), along
with the corresponding DVB Transponder. Reference Satellite is also
enabled or disabled under this menu.
DVB Allows the user to configure and save the Satellite DVB parameters such
as (DVB type, Frequency, symbol rate etc...), and LNB Power
Requirement.
SR_CP Allows the user to configure and save the search mode (RF Search or
DVB mode), Compass, RF Threshold and AZ search window.
BR Beacon configuration for each Satellite.
PWD:: ********
RST :: *********
Fig. 29: Password screen
SAT DVB SR_CP BR
Fig. 30: Beam Configuration Menu
