step-through-search moving the AZ axis in small incremental steps, this method increases the
search time.
Enable Reference Satellite
If this checkbox is selected, the Reference Satellite Option becomes active.
The reference satellite option is useful when the user cannot find a DVB transponder on the
desired target satellite. The user may select a reference satellite with a known DVB
Transponder from the configured list of Beams that are already saved, or a new Beam can be
configured. The iNetVu
that point to the desired target satellite, and peak on the modem signal. Does not work if search
method selected is RF Search.
Enable Inclined Satellite & Re-peak Period
Enabling this option will allow the system to maintain signal with an inclined orbital satellite. The
user may select the time difference between each re-peak on the inclined orbital satellite without
disabling the transmitter and maximizing on the signal strength. This feature has been modified
to support Ka platforms' that shift off signal due to shifting ground and or environment
conditions. The inclined mode routine will exit its operation once the Stop button is depressed
leaving the configuration selection enabled. The Inclined Satellite option will not work properly if
TX Protection is enabled at the same time and for this reason the TX Protection will be ignored
if it is enabled, since the Inclined Satellite option holds a higher priority. This option will get
disabled before starting ACP test mode. Disable the ACP Threshold feature if Inclined Satellite
search is required.
DIS: Disabled
1: Re-peak every 10 minutes
2: Re-peak every 30 minutes
3: Re-peak every 1 hours
4: Re-peak every 2 hours
5: Re-peak every 3 hours
6: Re-peak every 4 hours
7: Re-peak every 6 hours
8: Re-peak every 8 hours
9: Re-peak every 12 hours
8.2.4.5 Compass
Full Search
Performs a full 360º Azimuth search for the desired Satellite. This process may take up to 30
minutes to find and lock onto Satellite. Selecting Full Search will auto select Override
Compass and set the AZ Window to 180 or any other value (60 and above) depending on the
selected Platform type. This value can be overridden to a more desirable range. Override
Compass can be selected without selecting Full Search but this does not hold true for vice-
versa.
®
System will search and lock onto the reference satellite, then pivot from
