5 – Test Selection
Initiates the test on the specified axes according to the specified ranges, and speeds. Press up or
down key, first letter will flash then press ENTER, the test routine will start.
7.11.2.

DPLY

1
3
1 – Elevation Movement
User-defined elevation angle of deploy
2 – Polarization Movement
User-defined polarization angle of deploy
3 – Azimuth Movement
User-defined azimuth angle of deploy
4 – Deploy
Automatically moves antenna to the manually entered Elevation, Azimuth and Polarization
angles.
7.11.3.

DPLY_C

1
3
E: +20 P+60
A +180 DPLY
Fig. 47: Deploy Configuration
E: +20 P+60
A +180 CP_T
Fig. 48: Deploy Compass Reading Angles
