Before You Begin; Connecting To The Voip Network - Patton SmartNode SN10100A Series Quick Start Manual

In the box, you will find:
One SmartNode SN10100A
•
One set of mounting brackets with screws
•
One DB-9 to RJ-45 adapter
•
Three CAT5 Ethernet straight cables (male-male), three meters in length
•
One warranty sheet
•
One packing slip
•
One SmartNode SN10100A Series Quick Start Guide
•
One SmartNode SN10100A Important Notice sheet with unique information for your
•
specific unit
1. Install rack-mounting hardware on to the SN10100A and install the unit on the
equipment rack.
2. Connect the Ethernet port to your management network.
1. Connect the VoIP Ports 0/1 and 0/1 to your network (see
4

1.0 Before you begin

2.0 Installing the rack hardware
Figure 1.

3.0 Connecting to the VoIP Network

Installing the SN10100A
SmartNode 10100A Series Quick Start Guide
figure 2).
