In the box, you will find:
One SmartNode 10200A
•
One set of mounting brackets with screws
•
One DB-9 to RJ-45 adapter
•
SCSI Cables and Patch Panels, if applicable
•
Three RJ45 Ethernet Straight Cables (male-male)
•
One warranty sheet
•
One packing slip
•
One SmartNode 10200A Series Quick Start Guide
•
One SmartNode 10200A Important Notice sheet with unique information for your
•
specific unit
Two AC power cords
•
To install the SN10200A, you will need (not included):
19-inch equipment rack
•
1. Install rack-mounting hardware on to the SN10200A and install the unit on the
equipment rack.
2. Connect the Ethernet port to your management network.
4

1.0 Before you begin

2.0 Installing the rack hardware
Figure 1.
Installing the SN10200A
SmartNode 10200A Series Quick Start Guide
