Failure
Product leakage from the leakage drain
Air leakage from the leakgae drain
When damaged seals are changed, generally all seals should be replaced.
For valve service actions SPX FLOW supplies complete seal kits.
(see spare parts lists) .
13

12. Trouble Shooting

13. Spare Parts Lists

The reference numbers of the spare parts for the different valve
designs and sizes are included in the attached spare parts drawings
with corresponding lists.
Please indicate the following data to place an order for spare parts:
- required number of parts
- reference number
- designation.
Remedy
Replace the disc diaphragm (6).
Check and replace flat diaphragm (7)
and o-rings (15, 16).
Data are subject to change.
UK

Constant Pressure Diaphragm Valve

DELTA CPV
Instruction Manual: UK – rev. 3
