2.5 Parameter Group 0 – Monitoring Parameters (Read Only)
Par. Description
st
P00-01 1 Analog input value (%)
nd
P00-02 2 Analog input value (%)
P00-03 Speed reference input (Hz / RPM)
P00-04 Digital input status
P00-05 User PI output (%)
P00-06 DC bus ripple (V)
P00-07 Applied motor voltage (V)
P00-08 DC bus voltage (V)
P00-09 Heatsink temperature (ᵒC)
P00-10 Run time since date of manuf. (Hours)
P00-11 Run time since last trip (1) (Hours)
P00-12 Run time since last trip (2) (Hours)
P00-13 Trip Log
P00-14 Run time since last disable (Hours)
P00-15 DC bus voltage log (V)
P00-16 Heatsink temperature log (V)
P00-17 Motor current log (A)
P00-18 DC bus ripple log (V)
P00-19 Internal drive temperature log (ᵒC)
P00-20 Internal drive temperature (ᵒC)
P00-21 CANopen process data input
P00-22 CANopen process data output
P00-23 Accumulated time with heatsink > 85ᵒC
(Hours)
P00-24 Accumulated time with drive internal temp >
80ᵒC (Hours)
P00-25 Estimated rotor speed (Hz)
P00-26 kWh meter / MWh meter
P00-27 Total run time of drive fans (Hours)
P00-28 Software version and checksum
P00-29 Drive type identifier
P00-30 Drive serial number
P00-31 Motor current Id / Iq
P00-32 Actual PWM switching frequency (kHz)
P00-33 Critical fault counter – O-I
P00-34 Critical fault counter – O-Volts
P00-35 Critical fault counter – U-Volts
P00-36 Critical fault counter – O-temp (h/sink)
P00-37 Critical fault counter – b O-I (chopper)
P00-38 Critical fault counter – O-hEAt (control)
P00-39 Modbus comms error counter
P00-40 CANbus comms error counter
P00-41 I/O processor comms errors
P00-42 Power stage uC comms errors
P00-43 Drive power up time (life time) (Hours)
P00-44 Phase U current offset & ref
P00-45 Phase V current offset & ref
P00-46 Phase W current offset & ref
P00-47 Index 1 : Fire mode total active time
Index 2 : Fire Mode Activation Count
P00-48 Scope channel 1 & 2
P00-49 Scope channel 3 & 4
P00-50 Bootloader and motor control
Optidrive E3 Advanced Technical Manual Issue 05.Docx
100% = max input voltage
100% = max input voltage
Displayed in Hz if P-10 = 0, otherwise RPM
Drive digital input status
Displays value of the User PI output
Measured DC bus ripple
Value of RMS voltage applied to motor
Internal DC bus voltage
Temperature of heatsink in ᵒC
Not affected by resetting factory default parameters
Run-time clock stopped by drive disable (or trip), reset on next enable only if a trip
occurred. Reset also on next enable after a drive power down.
Run-time clock stopped by drive disable (or trip), reset on next enable only if a trip
occurred (under-volts not considered a trip) – not reset by power down / power up
cycling unless a trip occurred prior to power down
Displays most recent 4 trips with time stamp
Run-time clock stopped on drive disable, value reset on next enable
8 most recent values prior to trip, 256ms sample time
8 most recent values prior to trip, 30s sample time
8 most recent values prior to trip, 256ms sample time
8 most recent values prior to trip, 22ms sample time
8 most recent values prior to trip, 30 s sample time
Actual internal ambient temperature in ᵒC
Incoming process data (RX PDO1) for CANopen: PI1, PI2, PI3, PI4
outgoing process data (TX PDO1) for CANopen: PO1, PO2, PO3, PO4
Total accumulated hours and minutes of operation above heatsink temp of 85ᵒC
Total accumulated hours and minutes of operation with drive internal ambient above
80C
In vector control modes, estimated rotor speed in Hz
Total number of kWh / MWh consumed by the drive.
Time displayed in hh:mm:ss. First value displays time in hrs, press up to display
mm:ss.
Version number and checksum. "1" on LH side indicates I/O processor, "2" indicates
power stage
Drive rating, drive type and software version codes
Unique drive serial number
Displays the magnetising current (Id) and torque current (Iq). Press UP to show Iq
Actual switching frequency used by drive
These parameters log the number of times specific faults or errors occur, and are
useful for diagnostic purposes.
Total lifetime of drive with power applied
Internal value
Internal value
Internal value
Total activation time of Fire Mode
Displays the number of times Fire Mode has been activated
Displays signals for first scope channels 1 & 2
Displays signals for first scope channels 3 & 4
Internal value
