2 Optidrive E3 Parameter Set Overview

2.1

About this section

This document provides a list of the available parameters, and a description of their respective functions, for the Optidrive E3.
2.2

Parameter Structure Overview and Access

The parameter set is arranged in Groups according to the following structure:-
Access to all parameter groups is controlled by setting P-14 as follows
P-14 = P-37 (Factory setting: 101) Allows Extended Parameter Access
P-14 = P-37 + 100 (Factory Setting: 201) Allows Advanced Parameter Access
In order to prevent possible damage to the drive and connected machinery, certain parameters are locked during operation of the drive to
prevent change. In the case that the drive is enabled, and the user tries to change the parameter, an "L" is shown on the left of the display.
6 / 69
Optidrive E3 Advanced Technical Manual Issue 05.Docx
Parameter Group Range
P00 P00-01 to P00-20
P00-21 to P00-50
Basic Parameters P-01 to P-14
Extended Parameters P-15 to P-50
Advanced Parameters P-51 to P-60
Access Level Access Type
Extended Read Only
Advanced Read Only
Basic Read / Write
Extended Read / Write
Advanced Read / Write
