Invertek Drives Optidrive iE3 Technical Manual page 2

Revision History
Issue Note
01 Pre Release
02 Added changes for V3.02 Firmware
P-30 new functions
P00-47 New functions
Revised I/O table P-15 selection
Added parameter changes for 1 Phase Output Drive
Added Voltage levels for 110V drives
Revised Fire Mode Operation Description
Added CAN & Modbus info for new P-30
03 Updated P-11 Max setting to "Drive Dependent"
Updated P-18 Maximum Setting = 9
Updated P-25 Added setting 11
Updated P-30 Correcting error to Index 3
Updated P-51 adding setting 5
Updated P-52 description to add note regarding setting 5 for P-51
Updated I/O function tables to improve clarity
04 Changes to include V3.03 Firmware
Additional settings added to P-43
Added field Gateway usage info
Added operating display info
Added introduction section
Added note regarding changing parameters when enabled
05 Changes to include V3.05 Firmware
Corrected motor control mode selection parameter range
Added additional P-01 upper limit info
Corrected range of P-05, P-10, increased range P-09
Revised order for switching frequency derating info
Added additional info for V3.05 firmware functions
- Additional parameter function in P-05 and P-06, additional info for P-13
- P-36 Index 3 new options
- P-60 function updated
- Added P-15 option 18
- Added P-15 option 18
- Added P-15 option 18
- Added P-15 option 18
Added information on 4kW reduced overload below 5Hz
Additional description of Effective Switching frequency changes
Corrected P-40 listing
Optidrive E3 Advanced Technical Manual Issue 05.Docx
Section Date
05/01/16
N/A 04/02/16
2.3.2
2.5
2.6
2.4
9.10.5
2.7.1
4.7.8
2.3.1 01/03/16
2.3.2
2.3.2
2.3.2
2.3.3
2.3.3
2.6.3
06/07/16
2.3.2
5
2.7.3
1
2.2
01/09/17
4.6.2
2.3.1
4.6.2
0
2.3.1
2.3.2
2.3.3
2.6.4
2.6.5
2.6.6
2.6.7
9.10.5
2.7.3
2.3.2 18/10/17
3 / 69
