V/F Mode Voltage Boost Setting Options - Invertek Drives Optidrive iE3 Technical Manual

Ac variable speed drive 0.37kw – 22kw / 0.5hp – 30hp 110 – 480 volt 1 & 3 phase
Hide thumbs
Table of Contents

Advertisement

3.2

V/F Mode Voltage Boost Setting Options

Optidrive E3 Advanced Technical Manual Issue 05.Docx
110 Volt, 1 Phase Input Models (Voltage Doubler)
Frame
kW
HP
Default
1
0.37
0.5
3.0%
1
0.75
1
3.0%
2
1.1
1.5
2.5%
230 Volt, 1 Phase Input Models
Frame
kW
HP
Default
1
0.37
0.5
3.0%
1
0.75
1
3.0%
1
1.5
2
3.0%
2
1.5
2
2.5%
2
2.2
3
2.5%
3
4
5
2.0%
230 Volt, 3 Phase Input Models
Frame
kW
HP
Default
1
0.37
0.5
3.0%
1
0.75
1
3.0%
1
1.5
2
3.0%
2
1.5
2
2.5%
2
2.2
3
2.5%
3
3
4
2.0%
3
4
5
2.0%
4
5.5
7.5
1.5%
4
7.5
10
1.5%
4
11
15
1.5%
400 Volt 3 Phase Input Models
Frame
kW
HP
Default
1
0.75
1
3.0%
1
1.5
2
3.0%
2
1.5
2
2.5%
2
2.2
3
2.5%
2
4
5
2.5%
3
5.5
7.5
2.0%
3
7.5
10
2.0%
3
11
15
2.0%
4
15
20
1.5%
4
18.5
25
1.5%
4
22
30
1.5%
Maximum
25.0%
25.0%
20.0%
Maximum
25.0%
25.0%
25.0%
20.0%
20.0%
15.0%
Maximum
25.0%
25.0%
25.0%
20.0%
20.0%
15.0%
15.0%
10.0%
10.0%
10.0%
Maximum
25.0%
25.0%
20.0%
20.0%
20.0%
15.0%
15.0%
15.0%
10.0%
10.0%
10.0%
