C a l i p e r P i s t o n R e m o v a l
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (e.g. your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
1 Disconnect the hose from the banjo.
Fluid will drip. Place an oil pan and/or rag under the hose.
2
Install the caliper into the soft jaws of a vise. Remove the banjo bolt.
Set the banjo aside.
3 Remove the caliper body bolt.
4 Separate the caliper body halves.
NOTI CE
N OT ICE
6 and 9 mm
8 mm
T25
8 and 10 mm Flat and Post mount
Connectamajig™
T25
Post Mount
T25
Post Mount

Caliper Piston Removal

Flat Mount
Flat Mount
10
