Caliper Piston Removal - SRAM Guide DB5 Service Manual

C a l i p e r P i s t o n R e m o v a l
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (i.e. your frame) or printing on the brakes,
wipe it off immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not
covered under warranty.
Use an 8 mm open end wrench to remove the banjo bolt.
1
Set the hose and banjo fitting aside.
Use a T25 TORX® wrench to remove the caliper body bolt.
2
3 Separate the caliper body halves.
N O T I C E
8 mm open end wrench
T25 TORX wrench

Caliper Piston Removal

25
