14.3 Remove a unit and insert another unit of the
same type
Scenario during normal operation /
actions to be carried out
For example, remove an optical smoke detector BH-300 and insert another optical smoke detector
BH-300.
1
Remove the detector from its base.
2
Acknowledge all faults.
3
Insert another detector of same
type in the base.
4
Acknowledge the fault.
5
In service menu, select System
Settings/Save Configuration, then
Restart System.
14.4 Remove a unit and insert another unit of a
different type
Scenario during normal operation / actions to be
carried out
For example, remove an optical smoke detector BH-300 and insert a heat detector BD-300.
1
Remove the detector from its base.
2
Acknowledge all faults.
3
Insert a detector of a different type in the base.
4
Acknowledge the faults.
5
Enter service mode.
Select fault warning
"Loop Unit not responding" .
6
Select function "Remove Unit from
Configuration".
7
Select the fault warning: "Unit Replaced.
Transfer Config."
8
If you want to keep the previous properties,
select the function "Transfer Config" (the name
and zone and control functions will be
transferred).
If you want to change the properties, select unit
configuration in this menu instead.
9
Configure the class settings manually.
10
In service menu, select System Settings/Save
Configuration, then Restart System.
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Panel indication (visual/audible)
Observe fault warnings "Open Circuit in negative wire" and
"Loop Unit not responding"
Buzzer off, indicator to steady
Observe fault warning
"Loop Unit Replaced"
Buzzer off, indicator to steady
After restart of system observe quiescent condition on panel.
Panel indication (visual/audible)
Observe fault warnings "Open Circuit in negative wire"
and "Loop Unit not responding"
Buzzer off, indicator to steady
Observe fault warnings
"Unit Replaced. Transfer Config?"
"Configuration mismatch"
Buzzer off, indicator to steady
After restart of system observe quiescent condition on
panel.
Autronica Fire and Security AS
Page 77
Changes on the Detection Loop
