Mounting Drawings

7. Mounting Drawings
7.1 Hole Dimensions - Mounting Bracket for BS-210 and
BS-211
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
The Operator Panel BS-210 (an integrated part of the Fire Alarm
Control Panel BS-200) can be surface mounted onto a bracket on
the wall outside the Fire Alarm Control Panel's cabinet.
252.3
171
Autronica Fire and Security AS
Page 16
69.5
