Panel 3
(BS-210/BU-210
etc)
Not connected
J13/3 24V IN 2
J13/4 0V IN 2
Not connected
Panel 2
(BS-210/BU-210
etc)
J13/5 A_1
J13/6 B_1
J13/3 24V IN 2
J13/4 0V IN 2
Not connected
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Cable 2b
Redundant Power between external panels
Pair 1
Pair 2 (both wires)
Pair 3 (both wires)
Pair 4
Cable 3
From last external panel and back to Fire
Alarm Control Panel
Pair 1+
Pair 1-
Pair 2 (both wires)
Pair 3 (both wires)
Pair 4
See drawing, chapter 9.11.
Autronica Fire and Security AS
Page 23
Cable Specifications
Panel 1 Terminals
(BSA-200/J1)
Not
connected
24V IN 2 J14/3
0V IN 2 J14/4
Not
connected
Panel 1 Terminals
(BS-200)
Panel Bus J4/11
Out A
Panel Bus J4/12
Out B
+24V out 2 J1/7
0V out 2 J1/8
Not
connected
