User Manual DEV 2190

5.5.4.4.7 .surveillance.numberOfPowerSupplies

OID:
Syntax:
Access:
Description:
Note:

This value is used to determine the maximum index of the following table:

5.5.4.4.8 .surveillance.powerSupplyTable

With the .powerSupplyTable the status of each power supply module can be
checked.
5.5.4.4.8.1

.surveillance.powerSupplyTable.powerSupplyEntry.powerSupplyIndex

OID:
Syntax:
Access:
Description:
5.5.4.4.8.2

.surveillance.powerSupplyTable.powerSupplyEntry.powerSupplyStatus

OID:
Syntax:
Access:
Description:

5.5.4.4.9 .surveillance.numberOfFans

OID:
Syntax:
Access:
Description:
Note:

This value is used to determine the maximum index of the following table:

5.5.4.4.10 .surveillance.fanTable

With the .fanTable the status of each fan can be checked.

5.5.4.4.10.1 .surveillance.fanTable.fanEntry.fanIndex

OID:
Syntax:
Access:
Description:
90
.1.3.6.1.4.1.21035.41.3.7.0
INTEGER32
read-only
The number of power supplies. This type of device is equipped with
two (or three) power supply modules, thus "2" (or "3") is returned.
.1.3.6.1.4.1.21035.41.3.8.1.1.x
INTEGER32 (1..3)
not-accessible
A unique value for each table entry ranging between "1" and the
number of entries (defined by .numberOfPowerSupplies, please
refer to chapter 5.5.4.4.7).
.1.3.6.1.4.1.21035.41.3.8.1.2.x
INTEGER {ok (1), notok (2), notapplicable (3)}
read-only
The status of the related power supply module, possible values:
"1" ok: no errors are reported for the power supply module;
"2" not ok: an error was detected for the power supply module;
"3" not applicable: is not returned for this type of device.
.1.3.6.1.4.1.21035.41.3.9.0
INTEGER32
read-only
The number of fans. This type of device is equipped with a single
fan (and monitoring module), thus "1" is returned.
.1.3.6.1.4.1.21035.41.3.10.1.1.x
INTEGER32 (1..16)
not-accessible
A unique value for each table entry ranging between "1" and the
number of entries (defined by .numberOfFans, chapter 5.5.4.4.9).
