Product Description

The Managed L-Band Distribution System DEV 2190 provides different communica-
tion features and can be equipped very flexible, thus enabling numerous different
RF signal distribution configurations.
At the front side the rack mountable 4 RU chassis provides space for up to 16 am-
plifier modules. At the rear side, the chassis provides horizontal slots for the distri-
bution of RF signals. These slots can be equipped with splitters, with combiners, or
with IRD controlled switches.
In the following, the general product structure is shown and the available options
are explained which can be installed in the DEV 2190. After that, the several
modules are described, followed by a few configuration examples.
3.1

Features and Options

3.1.1

Product Structure

At the front side, the DEV 2190 is equipped with up to three hot-pluggable power
supply modules (labeled PS
are explained in chapter 3.2.1) which are assembled horizontally above the other
modules.
A temperature controlled fan & monitoring module (F, chapter 3.2.2) installed at
the right provides status information and permits to change the operation mode of
the device.
The available slots (1...16) for amplifier modules (chapter 3.2.4) and for redundancy
switch modules (chapter 3.2.5) are located left to the fan & monitoring module.
