- Page 1 Customer Documentation DEV 2811 (C-Band, 1:8) DEV 2813 (C-Band, 1:16) DEV 2851 (Ku-Band, 1:8) DEV 2853 (Ku-Band, 1:16) Distribution Amplifiers DEV Systemtechnik GmbH Grüner Weg 4A 61169 Friedberg GERMANY Tel: +49 6031 6975 100 Fax: +49 6031 6975 114 support@dev-systemtechnik.com www.dev-systemtechnik.com...
-
Page 2: Table Of Contents
Customer Documentation DEV 281x, DEV 285x TABLE OF CONTENTS REVISION HISTORY ------------------------------------------------------------------------------- 2 INTRODUCTION ------------------------------------------------------------------------------------ 3 Warranty ----------------------------------------------------------------------------------------------- 3 Limitation of Warranty ------------------------------------------------------------------------------ 3 PRODUCT DESCRIPTION ----------------------------------------------------------------------- 4 Product Drawings ------------------------------------------------------------------------------------ 5 3.1.1 DEV 2811 ---------------------------------------------------------------------------------------------- 5 3.1.2 DEV 2813 ---------------------------------------------------------------------------------------------- 5 3.1.3... -
Page 3: Introduction
This customer documentation is intended to familiarize you with the installation and operation of the device. The DEV 28fx is a series of 1:8 (DEV 28f1) or 1:16 (DEV 28f3) distribution amplifiers designed for professional use. The DEV 281x products are used to distribute small C-Band signals in the range 3.2…4.2 GHz and the... -
Page 4: Product Description
Customer Documentation DEV 281x, DEV 285x PRODUCT DESCRIPTION This customer documentation covers the following products: 1:8 Distribution Amplifier; 3.2…4.2 GHz; 50 Ohm, SMA (f) DEV 2811 1:16 Distribution Amplifier; 3.2…4.2 GHz; 50 Ohm, SMA (f) DEV 2813 ... -
Page 5: Product Drawings
Customer Documentation DEV 281x, DEV 285x PRODUCT DRAWINGS As stated above there are available four different product versions. Structural and from the layout, the different versions are very similar. 3.1.1 DEV 2811 Front View: 1 :8 D is trib u tio n A m p lifie r 3 .2 ...4 .2 G H z... -
Page 6: Dev 2851
Customer Documentation DEV 281x, DEV 285x 3.1.3 DEV 2851 Front View: 1 :8 D is trib u tio n A m p lifie r 1 0 .9 5 … 1 2 .7 5 G H z P o w e r S u p p ly 1... -
Page 7: Installation Instructions
Customer Documentation DEV 281x, DEV 285x INSTALLATION INSTRUCTIONS SCOPE OF DELIVERY DEV 2811, or DEV 2813, or DEV 2851, or DEV 2853 Customer documentation (this document) INSTALLATION OF THE PRODUCT 4.2.1 Mechanical Integration of the Product For the integration in a 19" rack, the rack slots must be prepared with rails for the chassis. -
Page 8: Connection Of Rf Cables
- 1…4 & 5…8 of a 1:8 splitter (DEV 2811, DEV 2851) - 1…4 / 5…8 & 9…12 / 13…16 of a 1:16 splitter (DEV 2813, DEV 2853) and by connecting 50 Ohm SMA loads to the unused ports ... -
Page 9: Operation Of The Product
Customer Documentation DEV 281x, DEV 285x OPERATION OF THE PRODUCT After going through the installation steps as described above, the device is ready to use. There are no elements (buttons etc.) to be operated after power-up. The power supply operating status of the device is indicated via LEDs, which were already presented in chapter 3. -
Page 10: Conformance Declarations
Customer Documentation DEV 281x, DEV 285x CONFORMANCE DECLARATIONS CERTIFICATE OF CONFORMANCE Since DEV Systemtechnik develops and produces in Germany, the Certificate of Conformance for each product or product series is to be issued in German (as stated on the next page). - Page 11 Verantwortung, dass nachfolgend bezeichnete Produkte in denen von uns in Verkehr gebrachten Ausführungen: Bezeichnung der Produkte: Aktive C-Band oder Ku-Band Splitter 1:8 oder 1:16 Produktnummern DEV 2811, DEV 2813, DEV 2851, DEV 2853 Baujahr: ab 2008 auf die sich diese Erklärung bezieht, mit den folgenden Normen übereinstimmen.
- Page 12 Customer Documentation DEV 281x, DEV 285x (This Page Intentionally Left Blank) Copyright DEV Systemtechnik GmbH 2007-2017...
-
Page 13: Eu Declaration Of Conformity
Directive 2011/65/EU of the European Parliament and of the Council of 8-Jun-2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS). Signed for and on behalf of DEV Systemtechnik GmbH Name: Jörg Schmidt... -
Page 14: Glossary
Customer Documentation DEV 281x, DEV 285x GLOSSARY Alternating Current Light Emitting Diode Radio Frequency Rack Unit: Units of vertical height. 1 RU = 1 ¾" = 44.45 mm Sometimes simply referred to as "U" (Unit). SAT/IF SATellite Intermediate Frequency NOTES...
