Additionally, the default community for all four Trap Destination IP Addresses is set
to public and all configurable traps are disabled. If an address is defined without
explicit port assignment, the standard SNMP trap port 162 is assigned implicitly.
For changing the SNMP setup, please refer to chapter 5.4.7.2.2.
There are software factory defaults for some SNMP objects, please refer to the
corresponding chapters:

.application.controlMode

.application.portTable.portEntry.poEnable

.application.portTable.portEntry.poRfLimit

.application.portTable.portEntry.poBiasOnOff

.application.portTable.portEntry.poBiasLimitLo

.application.portTable.portEntry.poBiasLimitHi

.application.portTable.portEntry.poGain

.application.portTable.portEntry.poTilt

.surveillance.trapEnableMask

.surveillance.errorEnableMask
4.4

Communication Interface Configuration

Two hardware interfaces are provided at the CPU module for the communication
with the device: a serial interface and an Ethernet interface.
The serial interface can be used for the basic network setup and the Ethernet
interface is used for the operation via Web Interface or via SNMP.
4.4.1

Serial Interface

The Sub-D 9 pos female connector labeled "
interface is located at the CPU module; the pin assignment is stated in chapter 7.
The serial interface configuration is described by the following parameters:
Transmission rate:
Data bits:
Parity check:
Start/Stop bit:
Handshake:
4.4.2

Ethernet Interface

The connector labeled "
100Base-TX Ethernet interface; chapter 7 describes the pin assignment.
4.4.2.1

Ethernet Connection

If a standalone device is to be connected to a PC only, the connection can be
established via a direct Ethernet cable (or through a local hub/switch) between the
Ethernet connector of the device and the Ethernet connector of the PC. The net-
work setup of the PC is to be altered that it is in the same subnet as the device. If it
is intended to use the factory network settings, the IP address of the standalone PC
is to be set to
the device, e.g. set the IP address of the standalone PC to the default gateway
address
192.168.0.99
34
" at the CPU module is an RJ-45 jack for the standard
Ethernet
, with in the range
192.168.0.x x
.
