Front Panel Features - Extron electronics FPC 6000 Setup Manual

Download the cut-out template for the
1.
TLP Pro 1520MG from www.extron.com.
Print it at 100% (no scaling).
Use the template to mark the wall, cut the
2.
hole, and drill the four pilot holes.
The size of the cut-out hole is 8.90 inches
(22.61 cm) wide x 5.70 inches (14.48 cm) high.
The FPC 6000 ships, already mounted, in a
3.
rack-mountable metal panel. Remove the FPC
6000 from the panel and, remove the mounting
plate that is attached to the panel by screws.
Secure the mounting plate to the mounting
4.
surface with four #10 screws. The installer
must use screws and fasteners that are
appropriate for the mounting surface.
Run and connect cables to the back of the
5.
touchpanel (see
next page).
Insert the two provided Phillips pan head #6-
6.
32 x ¾-inch length screws with washers in the
mounting screw slot (see
next page). Leave a gap for the flange at the
bottom of the mounting plate to fit into.
Hold the touchpanel at a slight angle and
7.
lower the notches at the top of the back
panel (See figure 2,
mounting plate.
Swing the bottom of the touchpanel inwards
8.
so that it lies flat against the mounting plate
with the flange at the bottom of the mounting
plate sitting in a groove in the bottom of the
touchpanel.
Secure the touchpanel to the mounting plate
9.
with the mounting screws.

Front Panel Features

3
E E
FPC 6000 Front Panel
Figure 3.
Rear Panel Features on the
figure 4, J , on the
4
) over the hooks of the
A A B B C C
F F G G
1
1 1
3 3
2 2
Add the mounting plate. Align with
the wall box and mark holes for screws.
Secure the mounting plate
to the wall with screws (4).
Back View
Wall Mounting the FPC 6000
Figure 2.
D D
A
Communication LED — Lights briefly when unit is
powered on. Otherwise no function.
B
Status Light — Lights briefly when unit is powered on.
Otherwise no function.
C
Ambient Light Sensor — Monitors ambient light level and
adjusts screen brightness.
D
Capacative Touch Screen — A 15.6 inch screen with
1366x768 resolution.
E
Speakers — Provide audible feedback from button
presses.
F
Motion Sensor — Detects motion in front of the
touchpanel.
G
Menu Button — Activates the setup menu and calibration
screen (see
from under the touchpanel. It performs the same function
as the rear panel Menu button but is easier to reach when
the touchpanel is installed.
E E
NOTE:
Settings link on the
page 5) to open the on-screen menus.
Product Category
5 5
Hold the touchpanel at a slight angle.
Mount the touchpanel over the two
hooks on the mounting plate.
FPC 6000
4 4
Place the provided mounting screws (2)
with washers in the mounting screw slot
in the touchpanel.
6 6
Secure the touchpanel by tightening the
mounting screws against the base of the
mounting plate.
Setup Menu on page 4). It is accessed
Extron recommends using the FPC
Login Screen (see
3
