RS-232 9-Pin Female Connector
Pin
Abbreviation
1
CD
2
RX
3
TX
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
®
MultiModem
iCell MTCMR User Guide
Description
Carrier Detect
Receive
Transmit
Data Terminal Ready
Ground
Data Set Ready
Request to Send
Clear to Send
Ring Indicator
LEDS, CONNECTORS, AND SPECIFICATIONS
In/Out
O
O
I
I
--
O
I
O
O
37
