Mtcmr-E1 Specifications - Multitech MultiModem iCell User Manual

LEDS, CONNECTORS, AND SPECIFICATIONS
Category
Dimensions
Connectors
Cellular
RS-232
GPIO
Power
USB
Environment
Operating Temperature -22° to 185° F (-30° to 85° C)
Humidity
Power Requirements
Voltage
SMS
SMS
Certifications and Compliance
EMC Compliance
Radio Compliance
Safety Compliance
1
UL Listed at 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C
and has not been evaluated by UL for ambient greater than 40° C. "UL has evaluated this device for use in ordinary
locations only. Installation in a vehicle or other outdoor locations has not been evaluated by UL. UL Certification
does not apply or extend to use in vehicles or outdoor applications or in ambient above 40° C."

MTCMR-E1 Specifications

Category
General
Performance
Frequency Bands
Speed
20
Description
3.1 in x 4.9 in x 1.1 in (7.9 cm x 12.4 cm x 2.8 cm)
50 ohm SMA (female connector)
DE9
6 pin 2x3 style
2.5mm miniature (screw-on)
Type B
20%-90% relative humidity, non-condensing
9V to 32V DC
Point-to-Point messaging
Text and PDU
FCC Part 15 Class B
EN55022 Class B
FCC Part 22
FCC Part 24
UL/cUL 60950-1 2nd Ed
IEC60950-1 2nd Ed am.1
Description
EDGE: E-GPRS Class 12
GPRS: Class 10
Quad-band GSM/GPRS/EDGE: 850/900/1800/1900 MHz
1
MultiModem
®
iCell MTCMR User Guide
