MTCMR-G2 Specifications

Category
General
Performance
Frequency Bands
Speed
Packet Data
Circuit Switched Data
Physical Description
Weight
Dimensions
Connectors
Cellular
RS-232
GPIO
Power
USB
SIM Holder
Environment
Operating Temperature -40° to 185° F (-40° to 85° C)
Humidity
Power Requirements
Voltage
SMS, Wi-Fi, Bluetooth
SMS
Certifications and Compliance
EMC Compliance
®
MultiModem iCell MTCMR User Guide
Description
GPRS: Class 10
Quad-band GSM/GPRS/EDGE: 850/900/1800/1900 MHz
Up to 85.6K bps, coding schemes CS1 to CS4
Up to 14.4 Kbps transparent and non-transparent
0.45 lbs. (200 g)
3.1 in x 4.9 in x 1.1 in (7.9 cm x 12.4 cm x 2.8 cm)
50 ohm SMA (female connector)
DE9
6 pin 2x3 style
2.5mm miniature (screw-on)
Type B
Standard 1.8V and 3V
20%-90% relative humidity, non-condensing
9V to 32V DC
Point-to-Point messaging
Text and PDU
Cell broadcast
FCC Part 15 Class B
EN55022 Class B
LEDS, CONNECTORS, AND SPECIFICATIONS
