PRODUCT OVERVIEW

RS-232 9-Pin Female Connector

Pin Abbreviation
1 CD
2 RX
3 TX
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI

Power Draw MTC-G3

USB
5 volts
GSM850Mhz
Serial
7 volts
GSM850Mhz
9 volts
GSM850Mhz
32 volts
GSM850Mhz
10
Description
Carrier Detect
Receive
Transmit
Data Terminal Ready
Ground
Data Set Ready
Request to Send
Clear to Send
Ring Indicator
Cellular call box
connection no data
(amps)
0.040
Sleep Mode Cellular call box
Current (amps) connection no
data (amps))
0.015 0.041
0.012 0.034
0.005 0.017
In/Out
O
O
I
I
--
O
I
O
O
Average measured TX Pulse (AVG)
current (amps) at Amplitude Current
maximum power (amps)
0.238 1.14
Average
measured current
(amps) at
maximum power
0.167
0.132
0.056
Total inrush charge
measured in
MilliCoulombs (mC)
18.56
TX Pulse (AVG) Total inrush
Amplitude charge measured
Current (amps) in MilliCoulombs
(mC)
0.887 0.770
0.662 0.836
0.218 0.773
®
