Test and Troubleshoot

…
…

Network Communication Setup

Network setup is essential prior to configuration. Use the flowchart as a general guide to
setting up the control processor for network use.
Figure 6.
… Save the project.
…
Build and upload the system configuration to the control processor and other system
devices.
…
Test the system. See the Troubleshooting
of items to check during system troubleshooting.
…
Make adjustments to wiring or configuration as needed.
Network Communication Setup
Connect the PC and the LAN port or AV LAN
port of the control processor to
the same network.
Apply power to all devices.
Open the Toolbelt software from within
Global Con gurator (GC Professional or
GC Plus mode) or as the stand-alone
application.
Start Device Discovery.
Toolbelt displays a list of all Extron control
devices connected to the network.
Using the MAC address, locate the desired
control processor in the list and select it.
For each network interface
(LAN, or LAN and AV LAN), use the Set IP
feature in Toolbelt or use the
Toolbelt Manage > Network Settings tab
feature to enter the IP address and
subnet address, then con gure other
network settings as needed.
Network Setup
section starting on page 52 for an outline
