User's Manual
ce-info@camboard.de
CTL208CM
8-Button Control Panel Module
with Serial Control Output
68-836-01 Rev. A
Printed in the USA
07 03
Advertisement
Table of Contents
Related Manuals for Extron electronics CTL208CM
Summary of Contents for Extron electronics CTL208CM
- Page 1 Singapore 368363 Chiyoda-ku, Tokyo 102-0074 Japan 714.491.1500 +31.33.453.4040 +65.6383.4400 +81.3.3511.7655 Printed in the USA www.extron.com Fax 714.491.1517 Fax +31.33.453.4050 Fax +65.6383.4664 Fax +81.3.3511.7656 www.camboard.de Tel. 07131 911201 ce-info@camboard.de 07 03 © 2003 Extron Electronics. All rights reserved. Fax 07131 911203...
- Page 2 Precaucion evitar riesgo de electrocución, no intentar personalmente la reparación/ any particular use. In no event will Extron Electronics be liable for direct, indirect, Leer las instrucciones • Leer y analizar todas las instrucciones de mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar operación y seguridad, antes de usar el equipo.
- Page 3 Disconnect the serial control cable from the computer and install the serial control cable between the control panel module and the device to be controlled. www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Quick Start Guide QS-1 Fax 07131 911203...
-
Page 4: Table Of Contents
Installing the software ............4-2 Step 14 Starting the program ............4-3 Restore power to all devices. The installation is now complete. Using the software to program the CTL208CM ....4-5 Using the help system ............4-8 Serial Commands ..............4-9 Communications protocols ............ -
Page 5: Chapter 1 • Introduction
About the CTL208CM Features 68-836-01 Rev. A Printed in the USA 07 03 All trademarks mentioned in this manual are the properties of their respective owners. www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Table of Contents Fax 07131 911203... -
Page 6: About The Ctl208Cm
Four operating modes per button — Each button can be set to one of four operating modes: single (default), toggle, The Extron CTL208CM is a programmable 8-button control press/release, or continuous panel module that can be connected to any serial-controlled •... -
Page 7: Chapter 2 • Installation
CTL208CM Control Panel Module Chapter Two Installation Installation Overview UL Requirements for Wall Box Installation Wall Mounting Site Preparation Device Configuration Wall Mounting Rear Panel Setup www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Introduction Fax 07131 911203... -
Page 8: Installation Overview
If necessary, reconfigure the control panel module’s rear panel DIP switch 1 to match the serial protocol (RS-232, Run a serial cable between the site where the CTL208CM RS-422, RS-485) of the device to be controlled. See Rear control panel module will be installed and the site of the Panel Setup, in this chapter for details. -
Page 9: Ul Requirements For Wall Box Installation
The following Underwriters Laboratories (UL) requirements Installation using a UL listed wall box (available from Extron) is pertain to the installation of the CTL208CM into a wall or recommended for most mounting options, but the optional wall furniture (figure 2-1). -
Page 10: Device Configuration
If you are using a mounting bracket, follow the directions, if any, that came with the mounting bracket to attach the www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Installation CTL208CM Control Panel Module • Installation Fax 07131 911203... -
Page 11: Wall Mounting
Power on all devices. Rear Panel Setup All of the connectors and DIP switches necessary for connecting and configuring the CTL208CM are on the rear panel (figure 2-7). Figure 2-5 — Button locations 9 - 13 VDC Sandwich the mini-AAP panel (such as a CPM101) - Page 12 Off (0) if half duplex. * If the CTL is the last unit in a daisy chain. www.camboard.de Tel. 07131 911201 ce-info@camboard.de 2-10 CTL208CM Control Panel Module • Installation CTL208CM Control Panel Module • Installation 2-11 Fax 07131 911203...
-
Page 13: Chapter 3 • Operation
Vertrieb von CAMBOARD Electronics Installation, cont’d CTL208CM Control Panel Module Chapter Three Operation Button Modes Send Programmed Commands Factory Reset www.camboard.de Tel. 07131 911201 ce-info@camboard.de 2-12 CTL208CM Control Panel Module • Installation Fax 07131 911203... -
Page 14: Button Modes
When buttons are grouped, the CTL208 does not send the secondary command string for the button it deselects when you select a new button in the group. www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Operation CTL208CM Control Panel Module • Operation Fax 07131 911203... -
Page 15: Factory Reset
Ensure that you reset switch 5 to off (down). If you ICS100 Windows Control Program leave the switch on (up), the control panel module will reset every time you power it on. Serial Commands www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Operation Fax 07131 911203... -
Page 16: Ics100 Windows Control Program
If you want to specify a different directory, click on the Figure 4-2 — Serial Port Setup window Change Directory button. www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Serial Communications CTL208CM Control Panel Module • Serial Communications Fax 07131 911203... -
Page 17: Using The Software To Program The Ctl208Cm
Vertrieb von CAMBOARD Electronics Serial Communications, cont’d Click in the appropriate radio buttons to select the Using the software to program the CTL208CM desired settings. Use the control program to program the CTL208 buttons as Click Ok. follows: If you change the serial protocols, communications Click Inline Model >... - Page 18 If you selected single, press/release, or continuous a group. mode in step 3, the Button Codes window appears (figure 4-7). www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Serial Communications CTL208CM Control Panel Module • Serial Communications Fax 07131 911203...
-
Page 19: Using The Help System
From within the Button Codes window, press the F1 key. from responding to commands meant for another unit. www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Serial Communications CTL208CM Control Panel Module • Serial Communications Fax 07131 911203... -
Page 20: Control Panel Module Responses
ASCII or hex command string. Bracket position 1 = left bracket, 2 = right bracket. www.camboard.de Tel. 07131 911201 ce-info@camboard.de 4-10 CTL208CM Control Panel Module • Serial Communications CTL208CM Control Panel Module • Serial Communications 4-11 Fax 07131 911203... - Page 21 Operation. = Architectural information: C208•{serial #}•{Rev level}•{firmware #}•{firmware Rev level}•{available baud rates}1200,2400,4800,9600,19200,38400•{2 bytes for future use} www.camboard.de Tel. 07131 911201 ce-info@camboard.de 4-12 CTL208CM Control Panel Module • Serial Communications CTL208CM Control Panel Module • Serial Communications 4-13 Fax 07131 911203...
-
Page 22: Chapter One
Vertrieb von CAMBOARD Electronics Serial Communications, cont’d www.camboard.de Tel. 07131 911201 ce-info@camboard.de 4-14 CTL208CM Control Panel Module • Serial Communications CTL208CM Control Panel Module • Serial Communications 4-15 Fax 07131 911203... -
Page 23: Specifications
Vertrieb von CAMBOARD Electronics Serial Communications, cont’d CTL208CM Control Panel Module Appendix Reference Information Specifications Parts List www.camboard.de Tel. 07131 911201 ce-info@camboard.de 4-16 CTL208CM Control Panel Module • Serial Communications Fax 07131 911203... -
Page 24: Parts List
MTBF ..........30,000 hours Warranty ........3 years parts and labor Specifications are subject to change without notice. www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Reference Information CTL208CM Control Panel Module • Reference Information Fax 07131 911203... -
Page 25: Architectural Solutions
One-gang “J” box, 2.5” deep 980130 Two-gang “J” box, 2.5” deep 980084 Three-gang “J” box, 2.5” deep 980083 Four-gang “J” box, 2.5” deep 980097 One-gang mounting bracket IN9181 www.camboard.de Tel. 07131 911201 ce-info@camboard.de CTL208CM Control Panel Module • Reference Information Fax 07131 911203...
