INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
MT VERNON PELLET INSERT
ADVANCED ENERGY (AE)
MODEL(S):
MTVERNINSAE-MBK
MTVERNINSAE-PMH
MTVERNINSAE-CSB
CAUTION
Check building codes prior to installation:
•
Installation MUST comply with local, regional, state
and national codes and regulations.
•
Consult local building, fire officials or authorities
having jurisdiction about restrictions, installation
inspection, and permits.
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
R
7036-187M
WARNING
If the information in these instructions
is not followed exactly, a fire may result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
•
Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void your
warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fireplace.
•
Alert children and adults to hazards of high
temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
CAUTION
Tested and approved for wood pellets, shelled field corn,
wheat and black oil sunflower seeds. Burning of any
other type of fuel voids your warranty.
To obtain a French translation of this manual, please
contact your dealer or visit
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez
www.quadrafire.com
NOTE
www.quadrafire.com
August 13, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT VERNON and is the answer not in the manual?

Questions and answers

roger
February 2, 2025

burn **** has to much fuel back burning

0
1 comments:
Mr. Anderson
February 10, 2025

To fix excessive fuel back burning in a Quadra-Fire MT Vernon, check the following:

1. Airflow Adjustment – The only way to increase air is by switching to the high elevation setting, but this will reset any upgraded burn tables to default.
2. Feed Rate (Flame Height) – Adjust the feed rate to control flame height.
3. Ash Pan Seal – Ensure the ash pan is tightly seated to prevent air leaks.
4. Baffle Placement – Make sure the baffle is centered evenly and properly secured to avoid airflow issues.

These steps help regulate combustion and reduce back burning.
