Quadra-Fire CLASSIC BAY 1200I-C Owner's Manual
  1. Manuals
  2. Brands
  3. Quadra-Fire Manuals
  4. Stove
  5. CLASSIC BAY 1200I-C
  6. Owner's manual

Quadra-Fire CLASSIC BAY 1200I-C Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
OMNI-Test Laboratories, Inc.
EPA Standard of Performance for New Residential Wood Heaters
Certification Test Report
Non-Confidential Business Information
Manufacturer:
Heater Type:
Model:
Prepared for:
Prepared by:
Test Period:
Report Date:
Report Revision Date:
Report Number:
All data and information contained in this report are confidential and
proprietary to Hearth & Home Technologies. Its significance is subject to the
adequacy and representative character of the samples and to the
comprehensiveness of the tests, examinations, or surveys made. The contents of
this report cannot be copied or quoted, except in full, without specific, written
authorization from Hearth & Home Technologies and OMNI-Test Laboratories,
Inc. No use of the OMNI-Test Laboratories, Inc. name, logo, or registered mark
(O-TL) is permitted, except as expressly authorized by OMNI-Test Laboratories,
Inc. in writing.
(Non-CBI)
Hearth & Home Technologies, Inc.
Pellet-Fired, Insert
Classic Bay 1200I-C
Hearth & Home Technologies, LLC
352 Mountain House Rd.
Halifax, PA 17032
USA
OMNI-Test Laboratories, Inc.
13327 NE Airport Way
Portland, OR 97230
(503) 643-3788
December 18, 2018
February 1, 2019
February 19, 2024
0061PN013E
-Document Edition # 004 (02/19/2024)-
