Step 3
CONNECTING THE FRONT AND REAR FRAME
PARTS
• The rear frame (box II)
• The front frame
Note: Ask someone to assist you for this step, this will make things a lot easier.
1. Take the front frame out of the box and remove the protective materials.
2. Position the front frame onto the wheels and allow it to rest on the tilt guards.
4
3. The rear frame includes a connection piece with a large bolt (see figure 4). This bolt
has been hand-tightened for transport purposes only; remove the bolt.
Keep the removed bolt, nut and washer handy.
TOOLS
• Spanner # 30
