Nanolive 3D Cell Explorer-fluo User Manual page 39

10. Software STEVE
Interface Fluorescent
2D View
The 2D view shows a X-Y slice of the sample's Refractive Index overlaid with
user-defined digital stains and fluochromes resulting in a multi-channel image.
Sliders Area
Buttons Area
Digital Stain
Colouring Area
Transport Control
Panel Viewer
The Panel Viewer represents a 2D space of Refractive Index and Index Gradient.
Multi-channel images are not represented here.
Detailed Frame
Digital Stain Picker
Dialogue Window
3D View
The 3D view shows the stained data in three dimensions.
Time Line Area
Frame Intervals
3D Control Area
Fluorescence Sliders Area
