6.
Start-up
Installation and setup
10. Diverse connections of your 3D Cell Explorer-
•
Make sure the power switch of your 3D Cell Explorer-
•
Connect the Nanolive power cable to the Nanolive power supply. Then, plug the Nanolive power supply into the power port.
•
Plug the Nanolive USB 3.0 cable into the USB 3.0 port on the side of the 3D Cell Explorer (the camera), tightly screw the locks and connect
it to the USB 3.0 slot on your computer.
•
Plug the Nanolive USB 2.0 cable into the USB 2.0 port on the back of the 3D Cell Explorer-
your computer.
Figure 14
fluo
(Figure 14)
fluo
is off.
LLG
BNC cable
Power supply
cable
USB 2.0 cable
fluo
and connect it to one of the USB slots on
à
go back to contents
27
