Specifications; Installation Instructions - Altronix ALTV244UL Installation Manuals

Altronix ALTV244UL Series CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or
PTC protected outputs for powering CCTV cameras, heaters and other video accessories.
Four (4) Output ALTV244UL Reference Chart:
Altronix
Model Number
24VAC
ALTV244UL
28VAC
24VAC
ALTV244ULX
28VAC
24VAC
ALTV244ULCB
28VAC
24VAC
ALTV244175UL
28VAC
24VAC
ALTV244175ULCB
28VAC
Agency Listings:
• UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
• CE European Conformity.
Input:
• 115VAC, 50/60Hz.
Output:
• Four (4) fuse or PTC protected outputs.
• 24VAC or 28VAC output.
• Outputs are rated @ 3.5A (fused) or 2.5A (PTC).
• Surge suppression.
Features:
• Power ON/OFF switch
(ALTV244UL, ALTV244ULX, and
ALTV244ULCB).
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place
the enclosure's upper keyholes over the two upper screws, level and secure. Mark the position of the lower
two holes. Remove the enclosure. Drill the lower holes and install the three fasteners. Place the enclosure's
upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws
(Enclosure Dimensions, pgs. 10-12). Secure enclosure to earth ground.
2. Set power switch on power distribution board marked [PD] to OFF position for models ALTV244UL,
ALTV244ULX or ALTV244ULCB (Figs. 1-3, pgs. 4-6).
- 2 -
Overview:
3.5A
4 –
3A
3.5A
4 –
3A
3.5A
4
P
3A
7A
4 –
6.25A
7A
4
P
6.25A

Specifications:

Installation Instructions:

3.5A 3.5A
P
3.5A 3.5A
P
– 2.5A –
3.5A 3.5A
P
– 2.5A –
Features (cont'd):
• Illuminated power disconnect circuit breaker
with manual reset
(ALTV244175UL and ALTV244175ULCB).
• Unit maintains camera synchronization.
• Ease of installation saves time & eliminates
costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions (H x W x D):
• ALTV244UL, ALTV244ULCB
8.5" x 7.5" x 3.5"
(215.9mm x 190.5mm x 88.9mm).
• ALTV244175UL, ALTV24175ULCB
12" x 7.5" x 4.5"
(304.8mm x 190.5mm x 114.3mm).
• ALTV244ULX
13.5" x 13" x 3.25"
(342.9mm x 330.2mm x 82.6mm).
5A/ 3.5A/
0.9A
250V 250V
5A/ 3.5A/
0.9A
250V 250V
5A/ 3.5A/
0.9A
250V 250V
10A/
– 1.76A
250V
10A/
– 1.76A
250V
ALTV244UL Series
