ALTV244 Series
4-Output CCTV Power Supplies
Models Include:
ALTV244
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A (100VA).
- Four (4) Fuse Protected Outputs.
ALTV244175
- 24VAC @ 7.25A (175VA) or
28VAC @ 6.25A (175VA).
- Four (4) Fuse Protected Outputs.
ALTV244300
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Four (4) Fuse Protected Outputs.
Installation Guide
Rev. 020705
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
ALTV244CB
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A (100VA).
- Four (4) PTC Protected Outputs.
ALTV244175CB
- 24VAC @ 7.25A (175VA) or
28VAC @ 6.25A (175VA).
- Four (4) PTC Protected Outputs.
ALTV244300CB
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Four (4) PTC Protected Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix ALTV244 Series
Summary of Contents for Altronix ALTV244 Series
- Page 1 ALTV244 Series 4-Output CCTV Power Supplies Models Include: ALTV244 ALTV244CB - 24VAC @ 4A (100VA) or - 24VAC @ 4A (100VA) or 28VAC @ 3.5A (100VA). 28VAC @ 3.5A (100VA). - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs.
-
Page 2: Specifications
Overview: Altronix ALTV244 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Four (4) Output ALTV244 Reference Chart: Total Altronix Output Output Model Number... -
Page 3: Terminal Identification
(servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. ALTV244 Series Installation Guide - 3 -... - Page 4 Fig. 1 - ALTV244 and ALTV244CB PD4A POWER DISTRIBUTING UNIT INPUT 1P 1N 2P 2N 3P 3N 4P 4N used on ALTV244CB Input 115VAC, 50/60Hz, 0.9A Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 4 - ALTV244 Series Installation Guide...
- Page 5 PD4A POWER DISTRIBUTING UNIT 1P 1N 2P 2N 3P 3N 4P 4N used on ALTV244175CB Illuminated Power Switch Input 115VAC, 50/60Hz, 1.45A Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) ALTV244 Series Installation Guide - 5 -...
- Page 6 Fig. 3 - ALTV244300 and ALTV244300CB Illuminated Power Switch Input 115VAC, 50/60Hz, 2.7A used on ALTV244300CB Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 6 - ALTV244 Series Installation Guide...
- Page 7 (31.8mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 6.05” (153.7mm) 1.125” 1.125” (28.6mm) (28.6mm) 1” 1” (25.4mm) (25.4mm) 6.05” (153.7mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 1” (25.4mm) 5.25” (133.35mm) 1” 1” (25.4mm) (25.4mm) ALTV244 Series Installation Guide - 7 -...
- Page 8 1” 1” (25.4mm) (25.4mm) 7.25” (184.15mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIALTV244 Series J26U...
