ALTV244 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV244
- 24VAC @ 4 amp (100VA).
- Four (4) Fuse Protected
Outputs.
• ALTV244175
- 24VAC @ 7.25 amp (175VA)
or 28VAC @ 6.25 amp.
- Four (4) Fuse Protected
Outputs.
• ALTV244300
- 24VAC @ 12.5 amp (300VA).
or 28VAC @ 10 amp.
- Four (4) Fuse Protected
Outputs.
• ALTV244CB
- 24VAC @ 4 amp (100VA).
- Four (4) PTC Protected
Outputs.
• ALTV244175CB
- 24VAC @ 7.25 amp (175VA)
or 28VAC @ 6.25 amp.
- Four (4) PTC Protected
Outputs.
• ALTV244300CB
- 24VAC @ 12.5 amp (300VA).
or 28VAC @ 10 amp.
- Four (4) PTC Protected
Outputs.
Rev. 040704
Advertisement
Related Manuals for Altronix ALTV244 Series
Summary of Contents for Altronix ALTV244 Series
- Page 1 ALTV244 Series CCTV Power Supplies Installation Guide Models Include: • ALTV244 • ALTV244CB - 24VAC @ 4 amp (100VA). - 24VAC @ 4 amp (100VA). - Four (4) Fuse Protected - Four (4) PTC Protected Outputs. Outputs. • ALTV244175 • ALTV244175CB - 24VAC @ 7.25 amp (175VA)
-
Page 2: Specifications
Overview: These Altronix CCTV Power Supplies provide 24VAC distributed via four (4) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. Four (4) Output ALTV244 Reference Chart: Altronix Model Number ALTV244 4 amp 24VAC 3.5 amp 5 amp/250VA .9 amp... -
Page 3: Terminal Identification
7. Slide switch SW1 to ON position (Models ALTV244 and ALTV244CB), (Fig. 1, pg. 3). Turn main switch on all other models to the “RESET” (ON) position. 8. Green LED will illuminate when unit is powered. 9. Upon completion of wiring, secure enclosure door with screws (supplied). Caution: Equipment to be installed / serviced by authorized / trained personnel only. - Page 4 ALTV244 PD4A 1P, 2P, 3P, 4P = FUSED OUTPUTS 1N, 2N, 3N, 4N = COMMON OUTPUTS POWER DISTRIBUTING UNIT INPUT 24VAC fused output 1 (Follow same procedure using terminals 2P & N thru 4P & N fused outputs 2 thru 4) White Lead XFMR 115 VAC input...
- Page 5 ALTV244175 PD4A 1P, 2P, 3P, 4P = FUSED OUTPUTS 1N, 2N, 3N, 4N = COMMON OUTPUTS POWER DISTRIBUTING UNIT INPUT 24VAC or 28VAC fused output 1 (Follow same procedure using terminals 2P & N thru 4P & N fused outputs 2 thru 4) Power Switch Black...
- Page 6 ALTV244300 Power Switch Transformer underneath power supply board Black Lead White Lead ALTV244300CB Power Switch Transformer underneath power supply board Black Lead White Lead - 6 -...
- Page 7 Enclosure Dimensions for: • ALTV244 • ALTV244CB • ALTV244175 • ALTV244175CB • ALTV244300 • ALTV244300CB 8.5"H x 7.5"W x 3.5"D TOP ONLY - 7 -...
- Page 8 Note: Altronix is not responsible for any typographical errors. Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. MEMBER II1ALTV244Series D19D - 8 -...
