Altronix ALTV244UL Installation Manuals page 7

Fig. 4 - ALTV244175UL
Input 115VAC,
50/60Hz
Voltage Selection
Configuration
N P
24VAC
Output
24V
N P
28VAC
Output
28V
ALTV244UL Series
24VAC or 28VAC
Output 1
Follow same
procedure
using terminals
2P & N through
4P & N
1P
for outputs 2
through 4)
Illuminated Power Disconnect
Circuit Breaker with manual reset
non power-
limited
Black Lead
White Lead
Green
Lead
(ground)
S
28V
S
24V
3.5A 250V
3.5A 250V
1N 2P 2N 3P 3N 4P
Class 1 Outputs
3.5A 250V
LED
4N
N P S
- 7 -
