Installation Manual
ALTV244UL Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV244UL
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244ULX
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244175UL
- 24VAC @ 7A (175VA) or
28VAC @ 10A (300VA).
- Four (4) Fuse Protected Outputs.
Rev. 040506
ALTV244ULCB
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) PTC Protected Outputs.
ALTV244175ULCB
- 24VAC @ 7A (175VA) or
28VAC @ 10A (300VA).
- Four (4) PTC Protected Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix ALTV244UL
Summary of Contents for Altronix ALTV244UL
-
Page 1: Installation Guide
ALTV244UL Series CCTV Power Supplies Installation Guide Models Include: ALTV244UL ALTV244ULCB - 24VAC @ 3.5A (85VA) or - 24VAC @ 3.5A (85VA) or 28VAC @ 3A (85VA). 28VAC @ 3A (85VA). - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs. -
Page 2: Specifications
Overview: Altronix ALTV244UL Series CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Four (4) Output ALTV244UL Reference Chart: Altronix Model Number 24VAC 3.5A 3.5A/... -
Page 3: Terminal Identification
Code and all local codes. Use 75˚C or higher rated UL insulated wiring for connecting the unit to the mains. Replace fuses with the same type and rating (refer to Four (4) Output ALTV244UL Reference Chart, pg. 2). Terminal Identification:... - Page 4 Fig. 1 - ALTV244UL 3.5A 250V 3.5A 250V 3.5A 250V 24VAC or 28VAC Output 1 Follow same procedure Primary using terminals In-line 2P & N through 4P & N Fuse for outputs 2 through 4) Class 1 Outputs non power-...
- Page 5 2 through 4) 24VAC configuration Class 2 Not Wet/Class 3 Wet 28VAC configuration Class 1 non power- limited Black Lead Input 115VAC, 50/60Hz White Lead Green Lead XFMR (ground) Voltage Selection Configuration 24VAC Output 28VAC Output ALTV244UL Series - 5 -...
- Page 6 Fig. 3 - ALTV244ULX Class 1 Outputs MAIN FUSE Primary In-line Fuse non power- limited Green Lead (ground) Black Lead Input 115VAC, 50/60Hz White Lead Voltage Selection Configuration 24VAC Output 28VAC Output - 6 - ALTV244UL Series...
- Page 7 2 through 4) Class 1 Outputs Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead Input 115VAC, 50/60Hz White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Output 28VAC Output ALTV244UL Series - 7 -...
- Page 8 24VAC configuration Class 2 Not Wet/Class 3 Wet 28VAC configuration Class 1 Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead Input 115VAC, 50/60Hz White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Output 28VAC Output - 8 - ALTV244UL Series...
- Page 9 Notes: ALTV244UL Series - 9 -...
- Page 10 Enclosure Dimensions (H x W x D) for: • ALTV244UL • ALTV244ULCB 8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm) 7.25” (184.15mm) 3.625” (184.15mm) 1.25” (31.75mm) 3.5” (88.9mm) 0.6” 0.6” 1.25” 6.05” (15.24mm) (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125”...
- Page 11 (279mm) 0.9375” 1.40” (24mm) 1.40” (36mm) (36mm) 5.10” 5.10” (130mm) (130mm) 13.0” (330mm) 5.10” (130mm) 6.5625” (167mm) 0.9375” (24mm) 3.25” 3.25” (83mm) (83mm) 3.25” (83mm) 1.0” 1.0” (25mm) (25mm) 1.0” 10.5” 1.0” (25mm) (267mm) (25mm) ALTV244UL Series - 11 -...
- Page 12 (22.35mm) (22.35mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV244UL Series C30R...
