ALTV244UL3 Series
4-Output CCTV Power Supplies
with Factory Installed 3-wire Line Cords
Models Include:
ALTV244UL3
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244ULX3
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244175UL3
- 24VAC @ 7A (175VA) or
28VAC @ 10A (300VA).
- Four (4) Fuse Protected Outputs.
Installation Guide
Rev. 040406
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
ALTV244ULCB3
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) PTC Protected Outputs.
ALTV244175ULCB3
- 24VAC @ 7A (175VA) or
28VAC @ 10A (300VA).
- Four (4) PTC Protected Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix ALTV244UL3 Series
Summary of Contents for Altronix ALTV244UL3 Series
- Page 1 ALTV244UL3 Series 4-Output CCTV Power Supplies with Factory Installed 3-wire Line Cords Models Include: ALTV244UL3 ALTV244ULCB3 - 24VAC @ 3.5A (85VA) or - 24VAC @ 3.5A (85VA) or 28VAC @ 3A (85VA). 28VAC @ 3A (85VA). - Four (4) Fuse Protected Outputs.
-
Page 2: Specifications
Overview: Altronix ALTV244UL3 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Four (4) Output ALTV244UL3 Reference Chart: Altronix Model Number 24VAC 3.5A 3.5A/... -
Page 3: Installation Instructions
(servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. ALTV244UL3 Series Installation Guide - 3 -... - Page 4 2 through 4) Class 1 Outputs non power- limited Black Lead White Lead Green Lead (ground) XFMR Voltage Selection Input 115VAC, 50/60Hz Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 4 - ALTV244UL3 Series Installation Guide...
- Page 5 24VAC configuration Class 2 Not Wet/Class 3 Wet 28VAC configuration Class 1 non power- limited Black Lead White Lead Green Lead (ground) XFMR Voltage Selection Input 115VAC, Configuration 50/60Hz 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) ALTV244UL3 Series Installation Guide - 5 -...
- Page 6 Fig. 3 - ALTV244ULX3 Class 1 Outputs MAIN FUSE Primary In-line Fuse non power-limited Black Lead White Lead Input 115VAC, 50/60Hz Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 6 - ALTV244UL3 Series Installation Guide...
- Page 7 Class 1 Outputs Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Input 115VAC, Output 50/60Hz (Yellow) (Black) 28VAC Output (Black) (Yellow) ALTV244UL3 Series Installation Guide - 7 -...
- Page 8 28VAC configuration Class 1 Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Input 115VAC, Output 50/60Hz (Yellow) (Black) 28VAC Output (Black) (Yellow) - 8 - ALTV244UL3 Series Installation Guide...
- Page 9 Notes: ALTV244UL3 Series Installation Guide - 9 -...
- Page 10 (31.8mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 6.05” (153.7mm) 1.125” 1.125” (28.6mm) (28.6mm) 1” 1” (25.4mm) (25.4mm) 6.05” (153.7mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 1” (25.4mm) 5.25” (133.35mm) 1” 1” (25.4mm) (25.4mm) - 10 - ALTV244UL3 Series Installation Guide...
- Page 11 (30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0” (279.4mm) 0.9375” (23.8mm) 1.40” 1.40” (35.6mm) (35.6mm) 0.9375” (23.8mm) 3.25” (82.6mm) 3.25” (82.6mm) 1.0” (25.4mm) 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) ALTV244UL3 Series Installation Guide - 11 -...
- Page 12 1” (25.4mm) 0.88” (22.4mm) 5.75” (146.1mm) 0.88” (22.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIALTV244UL3 Series...
