Table of Contents

ALTV244220 Series
CCTV Power Supplies

Installation Guide

Models Include:
• ALTV244220
- 24VAC @ 4 amp (100VA)
or 28VAC @ 3.5 amp.
- Four (4) Fuse Protected Outputs.
• ALTV244175220
- 24VAC @ 7.25 amp (175VA)
or 28VAC @ 6.25 amp.
- Four (4) Fuse Protected Outputs.
• ALTV244300220
- 24VAC @ 12.5 amp (300VA).
or 28VAC @ 10 amp.
- Four (4) Fuse Protected Outputs.
• ALTV244CB220
- 24VAC @ 4 amp (100VA)
or 28VAC @ 3.5 amp.
- Four (4) PTC Protected Outputs.
• ALTV244175CB220
- 24VAC @ 7.25 amp (175VA)
or 28VAC @ 6.25 amp.
- Four (4) PTC Protected Outputs.
• ALTV244300CB220
- 24VAC @ 12.5 amp (300VA).
or 28VAC @ 10 amp.
- Four (4) PTC Protected Outputs.
Rev. 020705

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALTV244220 and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix ALTV244220

Summary of Contents for Altronix ALTV244220

  • Page 1: Installation Guide

    ALTV244220 Series CCTV Power Supplies Installation Guide Models Include: • ALTV244220 • ALTV244CB220 - 24VAC @ 4 amp (100VA) - 24VAC @ 4 amp (100VA) or 28VAC @ 3.5 amp. or 28VAC @ 3.5 amp. - Four (4) Fuse Protected Outputs.

  • Page 2: Specifications

    Overview: ALTV244220 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. Four (4) Output ALTV244220 Reference Chart: Total Output 220VAC Output Fuse Current...

  • Page 3: Terminal Identification

    7. Set main switch to the OFF position (Fig. 1-4, pgs. 4-5). 8. Connect devices to terminals marked [1P - 1N through 4P - 4N] on PD4/PD4CB board, carefully observing correct polarity (Fig. 1-4, pgs. 4-5). 9. Set main switch to the “RESET” (ON) position (Fig. 1-4, pgs. 4-5). 10.
  • Page 4 Fig. 1 ALTV244220 ALTV244175220 1P, 2P, 3P, 4P = FUSED OUTPUTS 1N, 2N, 3N, 4N = COMMON OUTPUTS INPUT 24VAC or 28VAC fused output 1 (Follow same procedure using terminals 2P & N thru 4P & N fused outputs 2 thru 4)
  • Page 5 Fig. 3 ALTV244300220 Power Switch Transformer underneath power supply board Voltage Selection Configuration 24VAC Output (Yellow) (Black) Fig. 4 ALTV244300CB220 28VAC Power Output Switch (Black) (Yellow) Transformer underneath power supply board ALTV244220series - 5 -...
  • Page 6 Enclosure Dimensions for: • ALTV244220 • ALTV244CB220 8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm) 7.25” (184.15mm) 3.625” (184.15mm) 1.25” (31.75mm) 3.5” (88.9mm) 0.6” 0.6” 1.25” 6.05” (15.24mm) (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125” (28.575mm) (28.575mm) 2” (50.8mm) 2”...
  • Page 7 Enclosure Dimensions for: • ALTV244175220 • ALTV244175B220 • ALTV244300220 • ALTV244300CB220 8.5” x 7.5” x 3.75” (215.9mm x 191mm x 95mm). 3.63” (92.2mm) 1.25” (31.75mm) 3.85” (97.79mm) 7.25” (184.15mm) 0.6” 1.25” 1.25” (15.24mm) 0.6” (31.75mm) (31.75mm) (15.24mm) 1” 1” (25.4mm) (25.4mm) 0.9”...
  • Page 8 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. MEMBER II1ALTV244220series D09M - 8 - ALTV244220series...
