Fig. 1 - ALTV244UL
24VAC or 28VAC Output 1
Follow same procedure
using terminals
2P & N through 4P & N
for outputs 2 through 4)
Voltage Selection
Configuration
N P
24VAC
Output
24V
N P
28VAC
Output
28V
- 4 -
3.5A 250V
1P 1N 2P
Class 1 Outputs
S
28V
S
24V
3.5A 250V
2N 3P 3N 4P 4N
XFMR
3.5A 250V
LED
N
P S
non power-
limited
Black Lead
White Lead
Primary
In-line
Fuse
Input 115VAC,
50/60Hz
Green
Lead
(ground)
ALTV244UL Series
