ALTV244UL Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV244UL
- 24VAC @ 3.5A (85VA)
or 28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244ULX
- 24VAC @ 3.5A (85VA)
or 28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244175UL
- 24VAC @ 7A (175VA)
or 28VAC @ 6.25A (175VA).
- Four (4) Fuse Protected Outputs.
ALTV244ULCB
- 24VAC @ 3.5A (85VA)
or 28VAC @ 3A (85VA).
- Four (4) PTC Protected Outputs.
ALTV244175ULCB
- 24VAC @ 7A (175VA)
or 28VAC @ 6.25A (175VA).
- Four (4) PTC Protected Outputs.
Rev. 040506
Advertisement
Table of Contents
Related Manuals for Altronix ALTV244UL
Summary of Contents for Altronix ALTV244UL
-
Page 1: Installation Guide
ALTV244UL Series CCTV Power Supplies Installation Guide Models Include: ALTV244UL ALTV244ULCB - 24VAC @ 3.5A (85VA) - 24VAC @ 3.5A (85VA) or 28VAC @ 3A (85VA). or 28VAC @ 3A (85VA). - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs. -
Page 2: Specifications
Overview: The following Altronix CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. Four (4) Output ALTV244UL Reference Chart: Altronix Model Number 24VAC 3.5A 3.5A/... -
Page 3: Terminal Identification
National Electrical Code. Use 75˚C or higher rated UL insulated wiring for connecting the unit to the mains. Replace fuses with the same type and rating (refer to Four (4) Output ALTV244UL Reference Chart, pg. 2). Terminal Identification:... - Page 4 24VAC configuration Class 2 Not Wet/Class 3 Wet Fuse 28VAC configuration Class 1 non-power limited non-power limited Black Lead Black Lead 115VAC Input 60 Hz. XFMR Back Panel White Lead of Enclosure Green Lead (Ground) - 4 - ALTV244UL Series...
- Page 5 60Hz, 0.9A AC Input and protected outputs must leave cabinet through separate knockouts. 0.25" spacing must be provided between AC Input and low voltage wiring. For supply connection use wire rated for at least 90˚C. ALTV244UL Series - 5 -...
- Page 6 2 through 4) Fig. 5a INPUT 24VAC configuration Class 2 Not Wet/Class 3 Wet non-power Illuminated Power Disconnect limited Circuit Breaker with manual reset Black Lead 115VAC Input 60 Hz. White Lead XFMR Green Lead (Ground) - 6 - ALTV244UL Series...
- Page 7 Enclosure Dimensions (H x W x D) for: 7.25” (184.15mm) 3.625” • ALTV244UL (184.15mm) • ALTV244ULCB 1.25” (31.75mm) 8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm) 3.5” (88.9mm) 1.25” 0.6” 6.05” 0.6” (15.24mm) (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125”...
- Page 8 (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. IIALTV244UL Series E03Q MEMBER...
