Altronix ALTV244UL Installation Manuals page 5

Fig. 2 - ALTV244ULCB
24VAC or 28VAC Output 1
Follow same procedure
using terminals
2P & N through 4P & N
for outputs 2 through 4)
Voltage Selection
Configuration
N P
24VAC
Output
24V
N P
28VAC
Output
28V
ALTV244UL Series
1P 1N 2P
24VAC configuration Class 2 Not Wet/Class 3 Wet
28VAC configuration Class 1
S
28V
S
24V
2N 3P 3N 4P 4N
XFMR
Primary
In-line
LED
Fuse
N
P S
non power-
limited
Black Lead
White Lead
Input 115VAC,
50/60Hz
Green
Lead
(ground)
- 5 -
