ALTV244UL Series
4-Output CCTV Power Supplies
Models Include:
ALTV244UL
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244ULX
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) Fuse Protected Outputs.
ALTV244175UL
- 24VAC @ 7A (175VA) or
28VAC @ 10A (300VA).
- Four (4) Fuse Protected Outputs.
Installation Guide
Rev. 040506
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
ALTV244ULCB
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Four (4) PTC Protected Outputs.
ALTV244175ULCB
- 24VAC @ 7A (175VA) or
28VAC @ 10A (300VA).
- Four (4) PTC Protected Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix ALTV244UL Series
Summary of Contents for Altronix ALTV244UL Series
- Page 1 ALTV244UL Series 4-Output CCTV Power Supplies Models Include: ALTV244UL ALTV244ULCB - 24VAC @ 3.5A (85VA) or - 24VAC @ 3.5A (85VA) or 28VAC @ 3A (85VA). 28VAC @ 3A (85VA). - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs.
-
Page 2: Specifications
Overview: Altronix ALTV244UL Series CCTV Power Supplies provide 24VAC or 28VAC distributed via four (4) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Four (4) Output ALTV244UL Reference Chart: Altronix Model Number 24VAC 3.5A 3.5A/... -
Page 3: Installation Instructions
(servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. ALTV244UL Series Installation Guide - 3 -... - Page 4 2 through 4) Class 1 Outputs non power- limited Black Lead Input 115VAC, 50/60Hz White Lead Green Lead (ground) XFMR Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 4 - ALTV244UL Series Installation Guide...
- Page 5 24VAC configuration Class 2 Not Wet/Class 3 Wet 28VAC configuration Class 1 non power- limited Black Lead Input 115VAC, White Lead 50/60Hz Green Lead (ground) XFMR Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) ALTV244UL Series Installation Guide - 5 -...
- Page 6 Fig. 3 - ALTV244ULX Class 1 Outputs MAIN FUSE Primary In-line Fuse non power-limited Green Lead (ground) Black Lead White Lead Input 115VAC, 50/60Hz Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 6 - ALTV244UL Series Installation Guide...
- Page 7 Class 1 Outputs Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead Input 115VAC, 50/60Hz White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) ALTV244UL Series Installation Guide - 7 -...
- Page 8 28VAC configuration Class 1 Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead Input 115VAC, 50/60Hz White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 8 - ALTV244UL Series Installation Guide...
- Page 9 Notes: ALTV244UL Series Installation Guide - 9 -...
- Page 10 (31.8mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 6.05” (153.7mm) 1.125” 1.125” (28.6mm) (28.6mm) 1” 1” (25.4mm) (25.4mm) 6.05” (153.7mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 1” (25.4mm) 5.25” (133.35mm) 1” 1” (25.4mm) (25.4mm) - 10 - ALTV244UL Series Installation Guide...
- Page 11 (30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0” (279.4mm) 0.9375” (23.8mm) 1.40” 1.40” (35.6mm) (35.6mm) 0.9375” (23.8mm) 3.25” (82.6mm) 3.25” (82.6mm) 1.0” (25.4mm) 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) ALTV244UL Series Installation Guide - 11 -...
- Page 12 1” (25.4mm) 0.88” (22.4mm) 5.75” (146.1mm) 0.88” (22.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIALTV244UL Series...
