1.0 INTRODUCTION

The DTS is supplied as a complete kit that includes:
(1) Tension meter with accumulator and AC adapter with country
adapters (EU, US, UK)
(1) Certificate of compliance with the order 2.1 under EN 10204
(1) Operating Instructions
(1) Carrying case
NOTE: Unpack the tension meter and inspect it for shipping damage. Notices of
defect must be filed, in writing, at the latest within 10 days on receipt of the goods.

2.0 OVERVIEW OF OPERATING AND DISPLAY ELEMENTS

FIG. 1
13
1.
Filament guide
2.
Guide rollers
3.
Measuring roller
4.
Material to be measured
5. Display
6. USB interface / power connector
13. Adjustment wheel for material thickness compensator
(subject to model or measuring range, otherwise a cover cap is provided)
12 11 10 9 8 7 6
07.
08.
09.
10.
11.
12.
– 2 –
5 4 3
Thumbpiece
MEMORY key
Arrow key
ESC / EXIT key
SET / DAMP key
POWER / ZERO key
2 1
