Available Models - Check-line DTS-200 Operating Manual

Air humidity
Power supply
Housing material
Housing dimensions
Weight (net/gross)
7.2

Available models

Model
DTS-200
DTS-500
DTS-1000
DTS-2000
DTS-2500
DTS-4000
DTS-5000
DTS-10K
DTS-20K
DTS-30K
DTS-50K
DTS-60K-V1
International unit of tensile force: 1 cN = 1.02 g = 0.01 N, 1 daN = 1.02 kg = 10.0 N
*
Depending on model, either width of filament guide or outer distance between outside guide rollers
** Suitable for 95 % of all applications. PA = Polyamide Monofilament. If the material to be measured
differs significant from the SCHMIDT calibration material in diameter, rigidity, shape, etc., we
recommend calibration using customer supplied material.
Instruments with calibration on customer sample are not adjusted and calibrated on material 1.
*** The DTSB, DTSE, DTSF and DTSL models do not include a material thickness
compensator. They are calibrated only on material 1.
The DTSB is calibrated depending to the range on a textile ribbon or thin tape.
85% RH, max
LiPo Accumulator (approx. 40 hours continuous use,
chaging time aapro. 3.5 hours
Die-cast aluminum
265mm x 78.5 mm 46 mm (L x W x H)
Up to DTS-50K approx. 875 g / 1550 g
DTS-60K-V1 approx 1040 g / 2700 g
Tension
Ranges
cN
0.2 - 200.0
0.5 - 500.0
10 - 1000
20 - 2000
25 - 2500
40 - 4000
50 - 5000
0.1 - 10.00 daN
0.2 - 20.00 daN
0.3 - 30.00 daN
0.5 - 50.00 daN
0.6 - 60.00 daN
*Measuring
Head Width
mm Polyamide [PA]
Monofilament
66
66 0.12 + 0.20 mm Ø
66 0.20 + 0.40 mm Ø
66 0.40 + 0.70 mm Ø
116 0.40 + 0.70 mm Ø
66 0.50 + 0.80 mm Ø
116 0.60 + 1.20 mm Ø
116 0.80 + 1.40 mm Ø
116 1.20 + 1.80 mm Ø
216 1.40 + 2.00 mm Ø
216 steel rope 1.5 mm Ø
280 steel rope 2.0 mm
Ø(7 x 7 x 0.30)
– 21 –
**Factory
Calibration
Matretial 1
0.12 mm Ø
(7 x 7 x 0.15)
***Material
Thickness
Compensator
for Included
yes
yes
yes
yes
yes
yes
yes
yes
yes
