Check-line DTS-200 Operating Manual page 5

Graphic display
Info on material
Damping
Tension range
Measured values
as graph
Current reading
FIG. 4
The Y-axis can be scaled with the
3 Scalings: total measuring range, set limits range plus approx. 1/3 of
MAX.-alarm value and minus approx. 1/3 of MIN.-alarm value, set limits range.
The scaling is only possible, if limit values are entered and the damping is not
activated.
With the
60 sec.
The scaling can also be changed during the measurement, whereby values
already displayed are deleted when the X-axis is changed.
Adjusted material
diameter
Alarm values
or button the X-axis can be scaled. The setting range is 0.5 to
– 4 –
Memory mode (data
stored in the memory)
and buttons.
Battery status indicator
MAX.-alarm value
MIN.-alarm value
Measurement unit
MIN/MAX Alarm
