The factory setting for the damping factor is 5. The average shown on the display is
calculated as follows:
5.6 Using the ALARM function
Requirements
In the Material Setup menu, make sure that the MIN and MAX limit values have been
set for each material characteristic.
The limit value alarm can be enabled in the main menu.
5.7

Cal. adjustment

By performing a calibration adjustment, you can adjust a material characteristic
calibrated for a particular material to a different material or diameter without creating a
new material characteristic.
Requirements
1. Prepare the measuring setup as shown in Fig. 11
2. Make sure that the thumbpiece is in the adjustment position (Section 5.4).
3. Set the material thickness as described in Section 5.2.
4. Select the desired material (Section4.3).
5. Move the tension meter into the desired measuring position and carry out a zero
adjustment, if required.
Adjusting
1. Select the Cal. Adjustment menu item from the main menu (Fig. 12)
2. Insert the material to be measured (Section 5.4) and push the thumbpiece into the
measuring position.
5 old measured values + 4 new measured values
Damping can be changed in 9 steps from 01 = low damping:
1 old measured value + 8 new measured values
8 old measured values + 1 new measured value
9
9
to 9 = high damping:
9
–13 –
