  • Page 1 Installation Manual D-Series...
  • Page 2 © 2018 FLIR Systems, Inc. All rights reserved worldwide. No parts of this manual, in whole or in part, may be copied, photocopied, translated, or transmitted to any electronic medium or machine readable form without the prior written permission of FLIR Systems, Inc.

  • Page 3: Table Of Contents

    2.1.1 Serial and/or IP Communications ................ 13 2.1.2 Server Configuration ................... 13 2.2 Camera Bench Test ..................... 13 2.2.1 Set IP Address using the FLIR Discovery Network Assistant (DNA) ....14 2.3 Log into the Camera Web Page ................... 15 2.3.1 Live Video Page ....................16 2.3.2 Camera Control and Status .................

  • Page 4: D-Series Camera Installation

    This manual describes the installation of the D-Series cameras. If help is needed during the installation https://www.flir.com/support-center/support-hq/ process, please refer to for support. All installers and integrators are encouraged to take advantage of the training offered by FLIR; visit https://www.flir.com/support-center/training/ for more information. This manual includes the following topics: •...

  • Page 5: Camera Overview

    D-Series Camera Installation Camera Overview The D-Series camera is both an analog and an IP camera. The video from the camera can be viewed over a traditional analog video network or it can be viewed by streaming it over an IP network using MPEG-4, M-JPEG, and H.264 encoding.

  • Page 6: Camera Connection Options

    • Power connectors (qty 3) • Ethernet coupler (RJ-45 jacks at each end) Accessories are available from FLIR Systems, Inc. Contact your FLIR Dealer or integrator for up-to- date information. 1.5.2 Required Supplies The installer will supply the following items, as needed (specific to the installation).

  • Page 7: Location Considerations

    The D-Series camera should be mounted upright (ball up) or upside down (ball down), depending on the model ordered. The camera should be mounted such that the FLIR logo on the side of the camera is right-side up and readable.

  • Page 8: Prior To Cutting/Drilling Holes

    If using four M5 x 0.8 fasteners, the maximum depth of the fastener should not exceed 10.0 mm (0.394 in). Use Loctite 222 low strength threadlocker for the M5 fasteners. Refer to the ICD for additional information (FLIR Doc. # 427-9XXX-XX-19). (2.598) 66.00...

  • Page 9: Camera Connections

    D-Series Camera Installation Table 1-1: Mounting Specifications M5 bolt circle diameter 66 mm (2.598 in) 6X M5 X 0.8 fasteners, equally spaced at 60°; maximum fastener engagement 10 mm (.394 in) 1-1/2 in NPT threaded opening Do not loosen or remove the cable gland nut; doing so could result in damage to the camera unit Select a water-tight enclosure for the connections that allows adequate space for the cable connections.

  • Page 10: Camera Grounding

    D-Series Camera Installation The camera itself does not have an on/off switch. Generally the D-Series camera may be connected to a circuit breaker and the circuit breaker will be used to apply or remove power to the camera. If power is supplied to it, the camera will be powered on and operating.

  • Page 11: D-Series Camera Specifications

    Thermal Frame Rate NTSC: 30 Hz or 7.5 Hz or PAL: 25 Hz or 8.33 Hz Focal Focal Model Model Length Length D-348 48° × 39° 9 mm D-645 45° × 37° 13 mm D-334 34° × 28° 13 mm D-625 25°...
  • Page 12 D-Series Camera Installation Pan Angle/Speed Continuous 360°; 0.5° to 60°/sec Tilt from horizontal: 25° to -90° when ball down, Tilt Angle/Speed Pan/Tilt -25° to 90° when ball up/0.5° to 30°/sec Programmable presets Weight 18.2 lb (8.3 kg) 8” x 8” x 17" (Nominal) Dimensions (L,W,H) (203mm x 203mm x 432mm) General...

  • Page 13: Basic Operation And Configuration

    Once the camera is connected to a network and powered on, set camera network parameters using the FLIR Discovery Network Assistant (DNA) software, perform a bench test by using a web browser to view the video and control the camera, or view video in the local Network Video Management System (for example, FLIR Latitude ).

  • Page 14: Set Ip Address Using The Flir Discovery Network Assistant (Dna)

    Basic Operation and Configuration 2.2.1 Set IP Address using the FLIR Discovery Network Assistant (DNA) The D-Series camera is shipped with a static IP address: 192.168.250.116. Assuming the existing network uses IP addresses that are unique and different than the default address on the camera,...

  • Page 15: Log Into The Camera Web Page

    Basic Operation and Configuration Log into the Camera Web Page Use a web browser to connect to the camera’s web server using one of three User Names: user, expert, or admin (the default passwords are user, expert, and admin respectively). The user login can be used to do the initial bench test of the camera.

  • Page 16: Live Video Page

    NVR. If the live video is not displayed, refer to Help The Help menu displays software version information. If it is necessary to contact FLIR Technical Support for assistance, it will be helpful to have the information from this page on hand.

  • Page 17: Camera Control And Status

    Save snapshot Video stream This same web interface is used with various FLIR thermal cameras, some of which have different capabilities. As a result, different buttons in the control panel will appear for different FLIR cameras. Go to Preset position.
  • Page 18 Basic Operation and Configuration Toggle Video Source This button causes the active video source to be switched between the thermal IR camera Sensor > Devices > IR > Zoom Slave, pg. and the daylight camera. Also, refer to Toggle Polarity—IR only This button changes the way various objects are displayed in the image, for example, with hot objects displayed as white and cold objects as black, or vice versa.

  • Page 19: Camera Configuration

    Basic Operation and Configuration Pan/Tilt Home This button causes the camera to go to the Home position. To set a new Home position, hold the button for approximately 3 seconds. Go to Preset The D-Series camera can have a set of predetermined pan/tilt locations, each of which is known as a preset.
  • Page 20 Basic Operation and Configuration It is necessary to have control of the camera to make Setup changes. Changes made through the Setup menu have an immediate effect (it is not necessary to stop and restart the server). To use these settings at power up, it is necessary to save the changes.
  • Page 21 Basic Operation and Configuration IR > AGC ROI The IR camera adjustments to the region of interest (ROI) determine what portion of the image is used by the Automatic Gain Control (AGC) algorithm. By default all of the pixels in the image are considered;...
  • Page 22 Basic Operation and Configuration Contrast (Max Gain) can be used to increase contrast, especially for scenes with little • temperature variation (it may also increase noise due to increased gain). • Sharpness (DDE Gain) is used to enhance image details and/or suppress fixed pattern noise. Positive values increase Sharpness, while negative values soften the image and filter fixed pattern noise.
  • Page 23 Basic Operation and Configuration Surveillance > Scan List To setup Presets: position camera, select Preset ID Click Set Surveillance > Auto Scan To start Auto Scan: select width and speed, then select Start Set Autoscan parameters: select speed, select limits, click Save Relative Auto Scan (Surveillance mode) will scan the scene starting with the current position of the camera.

  • Page 24: Maintenance Menu

    Basic Operation and Configuration 2.4.3 Maintenance Menu When a user logs in as admin, a complete Maintenance menu is available. The basic camera configuration steps are accessed through the Maintenance menu, using the Server submenu on the left side of the page.The LAN Settings, Date and Time, Server Status, and Security Options selections are described below.
  • Page 25 Basic Operation and Configuration Server > Services > Date and Time The date, time, and time zone can be obtained from an NTP server, or can be entered manually. If the NTP mode is selected, the NTP server information can be entered. The NTP server address can be entered as a static address or can be obtained via DHCP.
  • Page 26 Basic Operation and Configuration Server > Server Status The Server Status page provides an indication of the current server status (either running or stopped) and buttons for starting or stopping the server and for rebooting the system. The Uptime section of the Server Status page shows how long the camera has been running, number of users, and the load on the camera processor.
  • Page 27 Basic Operation and Configuration Server > Security Options Use the Security Options page to restrict access through the camera web server to specific IP addresses and to set or change passwords. The admin login can change or set any password. The expert login can only configure the expert login password.
  • Page 28 Basic Operation and Configuration Sensor > Communications > Serial Remote In some installations, a serial device such as a keyboard, joystick, or other device is used to control camera functions such as pan/tilt or zoom. A serial device can also be used to access functions that are specific to thermal cameras, such as changing the polarity from white hot to black hot.
  • Page 29 When Use Preset Map File is set to Yes (the default), then presets (and special functions known as Aux commands) can be used to access certain settings that are specific to the FLIR thermal camera, such as switching between White Hot and Preset Map File, pg.
  • Page 30 CCTV camera, control commands that allow access to more advanced features, or features that are specific to a particular type of equipment, are available through extensions to the serial protocol. These extended commands are quite useful when controlling features that are specific to FLIR thermal cameras.
  • Page 31 Basic Operation and Configuration Table 2-2: Aux Functions (Continued) AUX OFF 2 IRChangeActiveSource AUX ON 3 TogglePlateauValue AUX OFF 3 IRToggleAGCType AUX ON 4 ToggleAutofocus AUX OFF 4 IRStartNUCCalibration AUX OFF 5 IRToggleLUTPalette AUX ON 6 IRToggleDDEGain AUX OFF 6 IRToggleAGCROI AUX ON 7 IRToggleFOV...
  • Page 32 27. Several types of third-party Video Management Systems Refer to (VMS) are supported by FLIR IP cameras. Because these systems tend to evolve and change over time, contact the local FLIR representative or FLIR Technical Support to resolve any difficulties or questions about using this feature.
  • Page 33 Basic Operation and Configuration Sensor > Devices > IR > Zoom Slave The Zoom Slave function is set from the IR web page. To slave the IR camera to the DLTV zoom select the IR web page and scroll down to Zoom Slave. Set to Yes Select zoom mode Select camera...
  • Page 34 By default, four video streams are enabled for the camera: Video 0, Video 1, Video 2, and Video 3. The streams are available for viewing from a client program such as FLIR Latitude, a stand-alone video player, or a third-party VMS including ONVIF systems. By default, Video 0 and Video 1 are from the IR sensor, while Video 2 and Video 3 are from the visible camera.
  • Page 35 (RTCP) and Real Time Streaming Protocol (RTSP). In the background, a “negotiation” takes place to establish a session between the client (such as FLIR Latitude, a third party VMS, or video player) and the camera. The ports which form a session are negotiated using a protocol such as RTSP. A client typically requests a video stream using its preferred settings, and the camera can respond with its preferred settings.
  • Page 36 Basic Operation and Configuration The Image Size parameter controls the video resolution and therefore can have a large impact on bandwidth usage. The higher the resolution, the larger the size of the frame and the higher the network bandwidth required. Table 2-3 provides the corresponding resolution for each setting. Table 2-3: Image Size Settings Image Size NTSC...
  • Page 37 Basic Operation and Configuration Files > Configuration The Configuration page allows the Nexus Server configuration to be displayed or backed up locally (on the camera). The configuration file can also be downloaded to another computer for backup, or a new configuration file can be uploaded from a computer to the camera. Shown at the top of the page is the configuration script file in a scrollable window.

  • Page 38: Thermal Imaging Overview

    Basic Operation and Configuration Files > Log > Field Support Log Scroll down and select the Download button under Field Support Log to download a zip file to the computer for field service evaluation. Thermal Imaging Overview The thermal camera makes an image based on temperature differences. In the thermal image, by default the hottest item in the scene appears as white and the coldest item is black, and all other items are represented as a gray scale value between white and black.

  • Page 39: Troubleshooting Tips

    RCA connection inside the camera and determine if it produces an image. If the camera still does not produce an image, contact the FLIR dealer or reseller who provided the camera, or contact FLIR directly (contact information is provided on the rear cover of this manual).
  • Page 40 Basic Operation and Configuration By default the camera will broadcast a discovery packet two times per second. Use the FLIR Discovery Network Assistant (DNA) or a packet sniffer utility such as Wireshark and confirm the packets are being received by the PC from the camera.
  • Page 41 Basic Operation and Configuration take some time to recover. The amount of time needed will depend on how long the camera was exposed to the sun. The longer the exposure, the longer the recovery time needed. visible camera thermal camera Figure 2-3: Images facing sun 427-9030-01-12 Version 140 March 2018...
  • Page 42 FLIR Systems, Inc. 6769 Hollister Ave Goleta, CA 93117 https://www.flir.com/support-center/support-hq/ Support: Corporate Headquarters FLIR Systems, Inc. 27700 SW Parkway Ave. Wilsonville, OR 97070 PH: +1 503.498.3547 FX: +1 503.498.3153 sales@flir.com Document: 427-9030-01-12 Version: 140 Date: March 2018...
